DIFFUSE POROUS WILLOW

NOTE: unless otherwise specifically stated, all of the images shown on this
page are of 1/4" square end grain cross sections shown at 12X with the top
of the image towards the bark and the bottom towards the pith so that
earlywood is towards the bottom of the growth rings and latewood is towards the top

to see all species with links to their anatomy page go here: species links

Willow ranges from diffuse porous to semi diffuse porous

Willow species (genus Salix) range from diffuse porous to semi diffuse porous but are is mostly diffuse porous so I have put them all here on one page for convenience in comparisons


general characteristics of willow end grain

• pores: sizes from tiny down to uncountable, sometimes in wavy patterns close to ulmiform
• growth rings: occasionally vague but usually clear to the naked eye due to marginal parenchyma and darker tissue at the end of the latewood
• rays: none visible



• sharpleaf willow / Salix acutifolia --- exceptionally sharp growth ring boundary
• peachleaf willow / Salix amygdaloides --- a good example of the wavy pore groups that sometimes occur in Salix species
• peachleaf willow / Salix amygdaloides --- a 1/4" x 1/2" cross section shown here at 6X and clearly semi diffuse porous



• weeping willow / Salix babylonica --- a 1/4" x 3/8" cross section shown here at 8X
• weeping willow / Salix babylonica
• weeping willow / Salix babylonica --- this is not a full growth ring



• corkscrew willow / Salix babylonica
• corkscrew willow / Salix babylonica --- a 1/4" x 5/12" cross section shown here at 7X
• Australian willow / Salix babylonica x alba --- although the ring boundaries are very hard to see in this pic, they are there. One problem is that unlike my normal 1200 grit fine sanding, this one was only done to 400 grit
• Australian willow / Salix babylonica x alba --- about 1/2 of a growth ring in a 1/3" x 1/4" cross sectoin shown here at 9X



• Bebb willow / Salix bebbiana
• Bebb willow / Salix bebbiana
• Bebb willow / Salix bebbiana



• goat willow / Salix caprea
• goat willow / Salix caprea
• Hooker willow / Salix hookerana



• coastal plain willow / Salix caroliniana
• pussy willow / Salix discolor
• pussy willow / Salix discolor --- a 1/4" x 1/3" cross section shown here at 9X
• pussy willow / Salix discolor --- a 1/4" x 1/3" cross section shown here at 9X



• sandbar willow / Salix exigua
• sandbar willow / Salix exigua
• sandbar willow / Salix exigua --- a 1/4" x 5/12" cross section shown here at 7X
• sandbar willow / Salix exigua --- a 1/4" x 5/12" cross section shown here at 7X



• arryo willow / Salix lasiolepsis
• Pacific willow / Salix lasiandra --- noticeably sparser pores than most



• shining willow / Salix lucida
• shining willow / Salix lucida --- relatively sparse pores



• crack willow / Salix fragilis
• crack willow / Salix fragilis --- heartwood of a piece; this is a 1/4" x 5/12" cross section shown here at 7X
• crack willow / Salix fragilis --- sapwood of the same piece
• crack willow / Salix spp.





• black willow / Salix nigra
• black willow / Salix nigra
• black willow / Salix nigra


• black willow / Salix nigra



• Scouler willow / Salix scoulerana
• Scouler willow / Salix scoulerana



• willow / Salix spp. --- a 5/12" x 5/8" cross section shown here at 5X; very low ring count necessitated the larger than usual image
• willow / Salix spp.
• swamp willow / Salix spp. --- clearly semi diffuse porous
