NOTE: unless otherwise specifically stated, all of the images shown on this
page are of 1/4" square end grain cross sections shown at 12X with the top
of the image towards the bark and the bottom towards the pith so that
earlywood is towards the bottom of the growth rings and latewood is towards the top
to see all species with links to their anatomy page go here:
species links
Woods from the mahogany family, Meliaceae, that are included on this page are:
The American mahoganies, genus Swietenia, including Honduran and Cuban
The African mahoganies, genus Khaya
Sapele and sipo, both of the genus Entandrophragma, which are often cited as replacements for African mahogany and which have very similar characteristics to Khaya species
the various species of Cedrela and Toona that are called Spanish cedar or something similar (but are not true cedars nor are they native to Spain --- these also have characteristics quite similar to the other species on this page
A more detailed discussion of the various species in the family Mahogany can be found here: MAHOGANY NAMES
parenchyma: vasicentric always present to varying degrees, terminal parenchyma always present but clarity varies, diffuse in aggregate parenchyma present in the Entandrophragmas
rays: plentiful and generally easily visible with a 10X loupe but never to the naked eye
growth rings: strong marginal parenchyma in the Swietenias, Cedrelas and Toonas, strong to non-existent marginal parenchyma in the Khayas
KYAYA species (the African mahoganies)
moderately sparse pores with vasicentric parenchyma and occasional radial multiples
terminal parenchyma that varies from strong to invisible in the same band
strong rays clearly visible at 10X
African mahogany / Khaya ivorensis --- parenchyma lines are fuzzy
African mahogany / Khaya senegalensis --- no parenchyma lines at all
African mahogany / Khaya spp. --- parenchyma lines are fuzzy and the lower one starts to disappear off to the left
African mahogany / Khaya spp. --- rays are particularly weak in this sample, as is the marginal parenchyma
African mahogany / Khaya spp.
African mahogany / Khaya spp. --- a 1/3" x 1/4" cross section shown here at 9X; parenchyma lines are very weak
African mahogany / Khaya spp.
African mahogany / Khaya spp.
African mahogany / Khaya anthotheca --- no parenchyma lines at all in the area where this pic was taken
East African mahogany / Khaya anthotheca --- these two are from nearby areas of the same sample
East African mahogany / Khaya anthotheca --- these two are from nearby areas of the same sample and this one is a 1/3" x 1/4" cross section shown here at 9X
East African mahogany / Khaya anthotheca --- these two are from nearby areas of the same sample
East African mahogany / Khaya anthotheca --- these two are from nearby areas of the same sample
African mahogany / Khaya grandifoliola
African mahogany / Khaya grandifoliola
African mahogany / Khaya nyasica
African mahogany / Khaya nyasica
African mahogany / Khaya spp. --- a 3/4" x 1/4" cross section shown here at 12x for the purpose of illustrating how in African mahogany, the terminal parenchyma lines will often just peter out within a fairly short distance. This does not happen in the Swietenia species, where they may be very crisp or pretty fuzzy but pretty much always unbroken, and is a solid way to distinguish between African mahogany and American mahogany.
SWIETENIA species (the American mahoganies)
moderately sparse pores with vasicentric parenchyma and occasional radial multiples
strong terminal parenchyma that does not fade out as it does in the Khaya species
strong rays clearly visible at 10X
Honduran mahogany: As seen here, the width of the section shown is 1 cm (.4 inches) shown here at about 9X. A HUGE enlargement of each is present and they are squares of .4cm / .4cm (.16" x .16") and they are shown at about 67X (when you click on these images). Corresponding higher resolution sections from the same area of the samples are shown directly below.
Honduran mahogany:As seen here, the width of the section shown is .22 cm (.09 inches) shown here about 9X. A HUGE enlargement of each is present and they are squares of .22cm / .22cm (.09" x .09") and they are shown at about 120X (when you click on these images). These were taken from the same area of the same sample as the corresponding lower-resolution images directly above.
Honduran mahogany (bigleaf mahogany)) / Swietenia macrophylla --- although this was identified as stated, the characteristics seem to me to be much more like sapele (Entandrophragma cylindricum)
Cuban mahogany: As seen here, the width of the section shown is 1 cm (.4 inches) shown here at about 9X. A HUGE enlargement of each is present and they are squares of .4cm / .4cm (.16" x .16") and they are shown at about 67X (when you click on these images). Corresponding higher resolution sections from the same area of the samples are shown directly below.
mahogany, Cuban (West Indies) / Swietenia mahagoni
mahogany, Cuban / Swietenia mahagoni
mahogany, Cuban / Swietenia mahagoni
Cuban mahogany:As seen here, the width of the section shown is .22 cm (.09 inches) shown here about 9X. A HUGE enlargement of each is present and they are squares of .22cm / .22cm (.09" x .09") and they are shown at about 120X (when you click on these images). These were taken from the same area of the same sample as the corresponding lower-resolution images directly above.
mahogany, Cuban (West Indies) / Swietenia mahagoni
mahogany, Cuban / Swietenia mahagoni
mahogany, Cuban / Swietenia mahagoni
Cuban mahogany / Swietenia mahagoni
Cuban mahogany / Swietenia mahagoni
Puerto Rican mahogany / Swietenia mahagoni --- a 1/3" x 1/3" cross section shown here at 9X
Cuban mahogany (West Indies mahogany) / Swietenia mahagoni
Cuban mahogany (West Indies mahogany) / Swietenia mahagoni
Cuban mahogany (West Indies mahogany) / Swietenia mahagoni
sapele --- The parenchyma lines in sapele are different from sipo in that they are straighter and always appear to be continuous bands. They differ from the Khaya and Swietenia mahoganies in that they are more numerous and are not, as nearly as I can tell, marginal. The pores in sapele are generally more numerous than in sipo.
sapele: As seen here, the width of the section shown is 1 cm (.4 inches) shown here at about 9X. A HUGE enlargement of each is present and they are squares of .4cm / .4cm (.16" x .16") and they are shown at about 67X (when you click on these images). Corresponding higher resolution sections from the same area of the samples are shown directly below.
sapele / Entandrophragma spp.
sapele / Entandrophragma cylindricum
sapele / Entandrophragma spp.
sapele:As seen here, the width of the section shown is .22 cm (.09 inches) shown here about 38X. A HUGE enlargement of each is present and they are squares of .22cm / .22cm (.09" x .09") and they are shown at about 120X (when you click on these images). These were taken from the same area of the same sample as the corresponding lower-resolution images directly above.
sapele / Entandrophragma spp.
sapele / Entandrophragma cylindricum
sapele / Entandrophragma spp.
sapele / Entandrophragma spp. --- these two are from nearby areas of the same sample
sapele / Entandrophragma spp. --- these two are from nearby areas of the same sample
sapele / Entandrophragma cylindricum
sapele / Entandrophragma cylindricum
sapele / Entandrophragma cylindricum
sapele / Entandrophragma cylindricum
sapele / Entandrophragma cylindricum
sapele / Entandrophragma cylindricum
sapele / Entandrophragma cylindricum
sapele / Entandrophragma cylindricum
sapele / Entandrophragma cylindricum
sapele / Entandrophragma cylindricum
sipo --- The parenchyma lines in sipo are different from sapele in that they are more wavy and do not always appear to be continuous bands. They differ from the Khaya and Swietenia mahoganies in that they are more numerous and are not, as nearly as I can tell, marginal. Sipo pores are generally sparser than in sapele.
sipo: As seen here, the width of the section shown is 1 cm (.4 inches) shown here at about 9X. A HUGE enlargement of each is present and they are squares of .4cm / .4cm (.16" x .16") and they are shown at about 67X (when you click on these images). Corresponding higher resolution sections from the same area of the samples are shown directly below.
sipo:As seen here, the width of the section shown is .22 cm (.09 inches) shown here about 38X. A HUGE enlargement of each is present and they are squares of .22cm / .22cm (.09" x .09") and they are shown at about 120X (when you click on these images). These were taken from the same area of the same sample as the corresponding lower-resolution images directly above.
sipo / Entandrophragma utile
sipo / Entandrophragma utile
sipo / Entandrophragma utile
sipo / Entandrophragma utile
sipo / Entandrophragma utile
sipo (utile) / Entandrophragma utile --- these two are from nearby areas of the same sample
sipo (utile) / Entandrophragma utile --- these two are from nearby areas of the same sample
sold to me as sapele but I'm not sure that's what it is
sold to me as sipo but I'm not sure that's what it is
These two pieces were sold to me as sapele and sipo, respectively, BUT ... as you can see, they have end grain characteristics that are (1) identical to each other and (2) NOT the same as EITHER sapele OR sipo. These include (1) multitudinous parenchyma bands, (2) numerous fairly long radial pore multiples, (3) even the pores that are not in radial multiples are mostly in radial strands, and (4) rays are barely discernible even with a 10X loupe. SO ... I'm dubious that these are either sapele OR sipo, BUT ... it is possible that they are some related species that is lumped in with either sapele or sipo, whichever happens to be what the loggers are supposed to be cutting that day. I also noticed in the face grain of both of these planks that they are lighter and show less grain on flat cut surfaces than what is generally the case for both sapele and sipo.
CEDRELA species
sparse pores with obvious vasicentric parenchyma
rays sometimes weak but always visible at 10X
terminal parenchyma is usually fuzzy and has some lighter tissue, making it very obvious
Spanish cedar / Cedrela montana --- 1/2" x 1/4" cross section shown here at 6X
Spanish cedar (red mountain cedar) / Cedrela montana
Spanish cedar (red mountain cedar) / Cedrela montana
Spanish cedar / Cedrela odorata
Spanish cedar / Cedrela odorata
Spanish cedar / Cedrela odorata
Spanish cedar / Cedrela odorata
Spanish cedar / Cedrela spp.
Spanish cedar / Cedrela huberi --- a 1/3" x 1/3" cross section shown here at 9X
Spanish cedar (cigar box cedar) / Cedrela huberi --- this is from a laminated sample
Argentine rose cedar (aka Spanish cedar) / Cedrela fissilis
Argentine rose cedar (aka Spanish cedar) / Cedrela fissilis
Argentine rose cedar (aka Spanish cedar) / Cedrela fissilis
Spanish cedar (Peruvian cedar) / Cedrela fissilis
Spanish cedar (cedro) / Cedrela fissilis
TOONA species
very sparse pores with vasicentric parenchyma and some radial pore multiples
rays are sometimes weak but clearly visible at 10X
terminal parenchyma ranges from sharp to fuzzy
growth ring boundaries generally well delineated, some radial pore multiples
NOTE: Toona sinensis (syn Cedrela sinensis) is solidly ring porous and is on the ring porous page rather than here with the rest of the Toona species
Spanish cedar / Toona calantas
Burma cedar (aka Spanish cedar) / Toona ciliata
Australian red cedar (aka Spanish cedar) / Toona ciliata
Australian red cedar (aka Spanish cedar) / Toona ciliata --- these two are from nearby areas of the same sample
Australian red cedar (aka Spanish cedar) / Toona ciliata --- these two are from nearby areas of the same sample
Australian red cedar (aka Spanish cedar) / Toona ciliata
Australian red cedar (aka Spanish cedar) / Toona ciliata
Australian red cedar / Toona australis --- these two are from nearby areas of the same sample
Australian red cedar / Toona australis --- these two are from nearby areas of the same sample
Spanish cedar / Toona spp. --- I am not confident in the ID of this piece
other mahoganies
miva mahogany / Dysoxylum mollisimum --- a 1/4" x 1/3" cross section shown here at 9X; banded parenchyma and very sparse pores. This is an Australian wood in the family Meliaceae and is slightly similar to the Spanish cedar species
